Stainless Steel 'Y' Bracket Rail Connector
  • Stainless Steel 'Y' Bracket Rail Connector
  • Stainless Steel 'Y' Bracket Rail Connector
  • Stainless Steel 'Y' Bracket Rail Connector

Stainless Steel 'Y' Bracket Rail Connector

Polished stainless steel 'Y' bracket rail mount with grub screw fastenings for securing rails inline and at a 60 degree angle.

Add to your basket...

Stainless Steel 'Y' Bracket Rail Connector - 22mm (DF129A)

Price:
£10.08
Quantity:

Stainless Steel 'Y' Bracket Rail Connector - 25mm (DF129B)

Price:
£10.55
Quantity:

Stainless Steel 'Y' Bracket Rail Connector - 30mm (DF129C)

Price:
£18.96
Quantity:

Stainless Steel 'Y' Bracket Rail Connector Information

A polished 316 stainless steel 'Y' bracket rail connector with grub screw fastenings for securing rails inline and at a 60 degree angle. The securing grub screws can be adjusted using an allen key.

The boat stanchion rail 'Y' bracket connector can be used for all sorts of applications on board and can be fitted using the three connecting holes. This inline and 60 degree pulpit rail joint allows for inline and angled rail connection on the boat.

Stainless Steel 'Y' Bracket Rail Connector Specifications

  DF129A DF129B DF129C
Internal Diameter 22mm (7/8") 25mm (1") 30mm (1 3/16")
Height 50mm
Width 57mm
Depth 28mm
Angle 60 Degrees
Rating AISI 316 Stainless Steel
